3.6kW 16A 32Amp Type 2 to Type 1 EV Charging Cable

Short Description:

EV Connector Cable Type 2 to Type 1 EV Charging Cable is designed to charge your electric car at public charging stations or dedicated charging points which may be installed at your home or office.Our EV charging cables are manufactured in a rigorous process for reliable quality, comply with EU RoHs and are CE and TUV certified. The material is TPU, which controls the outer diameter and keeps the cable soft when bent, and is also resistant to abrasion, oil, ozone, ageing, radiation and low temperatures, ensuring that the product can be used in a variety of environments and has excellent universality.


  • Rated Current: 16A ,32Amp
  • Operating Voltage: 110V~250AC
  • Insulation Resisitance: >1000MΩ
  • Therminal Temperature rise: <50K
  • Withstand Voltage: 2000V
  • Product Detail

    Product Tags

    Rated Current 16Amp 32Amp
    Operation Voltage AC  250V
    Insulation Resistance >1000MΩ  ( DC 500V )
    Withstand Voltage 2000V
    Pin Material Copper Alloy, Silver Plating
    Shell Material Thermoplastic,Flame Retardant Grade UL94 V-0
    Mechanical Life No-Load Plug In  / Pull Out >10000 Times
    Contact Resistance 0.5mΩ Max
    Terminal Temperature Rise <50K
    Operating Temperature -30°C~+50°C
    Impact Insertion Force >300N
    Waterproof Degree IP55
    Cable Protection Reliability of materials,antiflaming,pressure-resistant,
    abrasion resistance,impact resistance and high oil
    Certification TUV, UL , CE Approved
    Model Rated Current Cable Specification Cable Color Cable Length
    HENGYI-EVAE-16A 16 Amp 3 X 2.5mm² + 2 X 0.5mm² Black
    (5Meter ,10Meter)
    The length of the cable
    can be customized
    HENGYI-EVAE-32A 32 Amp 3 X 6mm²+2 X 0.5mm²
